Schneider Electric SA

APC by Schneider Electric Smart-UPS Network-grade Power

Item #: APWSMT1500
Tower - 3 Hour Recharge - 6.70 Minute Stand-by - 110 V AC Input - 120 V AC Output - Sine Wave - Serial Port - USB - 8 x NEMA 5-15R Receptacle(s) - 8 x Battery/Surge Outlet

  • Cold-start capable - Provides temporary battery power when the utility power is out.
  • Energy meter - Provides actual kilowatt hours of usage for energy conscious users.
  • Green mode - Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
  • High online efficiency - Reduces utility costs, generates less heat.
  • Intuitive LCD interface - Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
SMT1500
Manufacturer Website Address
https://www.schneider-electric.com
Brand Name
APC by Schneider Electric
Product Line
Smart-UPS
Product Name
Smart-UPS Network-grade Power
Marketing Information

Smart-UPS provides reliable network-grade power to protect your critical data and equipment from power problems. High online efficiency reduces utility costs and generates less heat. Green mode bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Energy meter provides actual kilowatt hours of usage for energy conscious users. Intuitive LCD interface provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys. Single outlet group may be controlled separately from the UPS for a discrete reboot of hung devices, sequenced on/off and noncritical load shedding. Cold-start capability provides temporary battery power when the utility power is out. Temporary-compensated battery charging prolongs the battery life by regulating the charge voltage according to battery temperature.

More from the Manufacturer

Product Type
Line-interactive UPS
Catalog
Catalog Page
Technical Information
Plug/Connector Type
NEMA 5-15
Receptacle Type
NEMA 5-15R
Receptacle Detail
8 x NEMA 5-15R
Number of Battery & Surge Outlets
8
Emergency Power OFF
Optional
Power Description
Load Capacity (VA)
1440 VA
Load Capacity (Watt)
1000 W
Input Voltage
110 V AC
Output Voltage
120 V AC
Waveform Type
Sine Wave
Interfaces/Ports
Serial Port
Yes
USB
Yes
Battery Information
Battery Characteristics
Spill-proof, Maintenance-free
Battery Chemistry
Lead Acid
Backup/Run Time (Full Load)
6.70 Minute
Backup/Run Time (Half Load)
23.90 Minute
Typical Battery Recharge Time
3 Hour
Hot Swappable
Yes
Physical Characteristics
Color Family
Black
Product Color
Black
Height
8.5"
Width
6.7"
Depth
17.3"
Form Factor
Tower
Weight (Approximate)
53 lb
Miscellaneous
Package Contents
  • Smart-UPS Network-grade Power
  • CD with software
  • Documentation CD
  • Smart UPS signalling RS-232 cable
  • USB cable
  • Certifications & Standards
    • UL 1449
    • cUL Listed
    • UL 1778
    • UL
    • FCC
    • CE
    • C-Tick
    Recycled
    No
    Post-consumer-waste%
    0%
    Assembly Required
    No
    Energy Star
    Yes
    Country of Origin
    Philippines
    Environmentally Friendly
    Yes
    3 Year
